  • Consistent Performance

    A highly sensitive, cooled MWIR sensor allows the camera to more accurately spot defects, increasing product quality. Industry-leading 27,000-hour cryocooler lifetime maximizes camera uptime for consistent production throughput.

  • Designed for Inspection

    Fast integration times ensure accurate temperature measurements on moving products and production lines. Low-latency, deterministic synchronization to external sources means thermal images are captured precisely when needed for decision support.

  • Ready for Automation

    Standard GigE Vision protocols, Rest API and a built-in web interfaces shorten implementation timelines.

Specifications
Digital I/O connector type
M12 12-pin A-coded, Male (shared with external power)
Digital Inputs
2x opto-isolated, Vin(low)= 0–1.5 V, Vin(high)= 3–25 V
Digital Outputs
3x opto-isolated, 0–48 V DC, max. 350 mA; solid-state opto relay; 1x dedicated as Fault output (NC)
EMC
EN55032:2015/A11:2020
EN55035:2017/A11:2020
FCC Part 15, Subpart B ClassA
KC C 9832 and KS C 9835
Mounting
With mounting plate - 2 × 1/4"-20 tapped holes, 1 × 3/8"-16; tapped hole, 4 × #10-24 tapped holes Without mounting plate - 6 × #6-32
f-number
f/2.5
Image Frequency
30 Hz
Thermal Sensitivity/NETD
≤15 mK at 25°C
Accuracy
≤100°C ±2°C, >100°C ±2% of reading
Communication & Data Storage
Command and Control
GEV: Genicam; RTSP: Web Interface, REST API
Communication Interfaces
Ethernet
Digital I/O connector type
M12 12-pin A-coded, Male (shared with external power)
Digital Inputs
2x opto-isolated, Vin(low)= 0–1.5 V, Vin(high)= 3–25 V
Digital Outputs
3x opto-isolated, 0–48 V DC, max. 350 mA; solid-state opto relay; 1x dedicated as Fault output (NC)
Storage Media
None
Synchronization Modes
Sync In
Imaging & Optical
Automatic Image Adjustment
Linear, manual, PE, DDE, ADE
Color Palettes
Selectable 8-bit
Detector Pitch
15 µm
Detector Type
High Operating Temperature (HOT) MWIR T2SLS
Digital image enhancement
High sensitivity mode (HSM)
Field of view (FOV)
31.5° × 25.5°
f-number
f/2.5
Focal Length
17 mm
Focus
Motorized
Image Frequency
30 Hz
Image Modes
IR image, high sensitivity mode (HSM)
IR Resolution
640 × 512
Minimum Focus Distance
60 mm (2.4 in)
Non-Radiometric IR Video
Streaming H.264 or MJPEG over RTSP
Non-radiometric IR video recording
None
Overlay
RTSP only
Radiometric IR video recording
None
Radiometric IR video streaming
GigE Vision
Sensor Cooling
FLIR FL100 Linear cooler
Spectral Range
3.4 μm - 5.1 μm
Thermal Sensitivity/NETD
≤15 mK at 25°C
Zoom
Digital zoom, 1x, 2x, 4x, 8x
Measurement & Analysis
Accuracy
≤100°C ±2°C, >100°C ±2% of reading
Ambient Drift Compensation [with factory cal]
Yes
DC Voltage
Range: 18 V-56 V
Object Temperature Range
-10°C to 120°C (14°F to 248°F)
General
Box Contents
Camera w/lens; M12 to RJ45F Cable (0.3 m), quick start guide, certificate of calibration
Size [L × W × H]
267 × 76 × 92 mm (10.5 in × 3.0 in × 3.6 in)
Size [L x W x H ] w/o Lens
200 × 76 × 92 mm (7.9 × 3.0 × 3.6 in)
Weight
1.77 kg (3.9 lbs)
Weight [without lens]
1.32 kg (2.9 lbs)
Environmental & Certifications
Directives
EMC: 2014/30/EU, WEEE: 2012/19/EU
EMC
EN55032:2015/A11:2020
EN55035:2017/A11:2020
FCC Part 15, Subpart B ClassA
KC C 9832 and KS C 9835
Encapsulation
IP50
Mounting
With mounting plate - 2 × 1/4"-20 tapped holes, 1 × 3/8"-16; tapped hole, 4 × #10-24 tapped holes Without mounting plate - 6 × #6-32
Operating Temperature Range
-20°C to 50°C (-4°F to 122°F)
Shock
25 g, 6 ms; Half sine; ±500 shocks; X,Y&Z (IAW MIL-STD-810H)
Vibration
10-58 Hz, 0.15 mm; 58-500 Hz, 2 g; 5 cycles, 1 oct/min; X,Y&Z (IAW MIL-STD-810H)
Power
Power Consumption
25 W (cool down)
Power Source
Primary power source: PoE+ type 2 (30 W min)
Optional DC connection: M12 12-pin A-coded, male (shared with Digital I/O)
